Anti Typhoon Die-casting A240W LED Area Flood Lights For Sport Courts Lighting , Billdbord Lighting
Features
• Using famous brand NICHIA 3030 LED chips.
• Corrosion resistance: Powder coating - The polishing lamp body anti fading and corrosion suitable for harsh outdoor environment.
• High quality accessories: water-proof connector and silicone rubber sealing suitable for harsh and tough environment.
• Heat Dissipation: professional terminal structure and Ferrari idea design, improving heat dissipation performance, prolonging lifetime.
• IP66 water-proof, dust-proof, corrosion proof.
• Easy to install, operation and maintenance.
• Anti typhoon: no deformation, loosening under wind tunnel test at the highest wind speed.
• Safe, energy-saving, no UV or IR radiation, no flickering / instant start up, no mercury.
• Long life of more than 50,000h, 5 years warranty.
Technich Data
| Power | 240W |
| Input Voltage | 90 - 305VAC |
| Input Current | 1.1A@220VAC |
| PF | >0.9@220VAC |
| DC Output Voltage | 48V |
| DC Output Current | 4.65A |
| Dimming (Optional) | 3 in one dimming(PMW, 1-10V,Resistor), DALI |
| CCT | 4000k, 5000k, 5700K, 3000K and 2700K can be customized |
| Ra>80,5000K | Typical Flu | 31200lm±10% |
| Efficiency | 130lm/W±10% |
| Ra>70,5000K | Typical Flux | 33600lm±10% |
| Efficiency | 140lm/W±10% |
| LED Brand | NICHIA 3030 |
| Light Type | Asymmetric and symmetric polarized light |
| Operation Temp. | -40 ℃ to + 45 ℃ |
| Storage Temp. | -40 ℃ to + 85 ℃ |
| Lifespan | 45℃ , 50,000 hours |
| IP Class | 66 |
| IK Class | 10 |
| Lamp Body Color | Grey or as customized |
| Product Size(mm) | 441*373*50 |
| Net Weight(kg) | 6.37 |
| Packing size(mm) | 540*460*190 |
| Gross Weight(kg) | 13.5 |
| Product Quantity Per Carton | 2pcs |
| Installation Method | Bracket Mount |
Product Size
Beam Angle
ANB AWB SNB SWB
Installation Manual
Applications
Garden Lighting,Park Lighting,Billboard Lighting,Landscape Lighting,Building Lighting,Sport Court Lighting.
